Overview
The Patton DialFire™ Model 3120 Remote Access Server supports up to 120 digital ISDN or analog (V.110, V.92, V.90, K56Flex, V.34, etc.) modem connections in a single 1U high (1.75 in./4.45 cm) rack-mountable chassis. The Model 3120 is the highest density, lowest profile remote access server available anywhere. It has two 10/100-Mbps Ethernet ports for load sharing and traffic balancing.


	Removable dual-redundant power standard—Supports two AC (115VAC or 230VAC), two DC, or a mix of AC (115VAC or 230VAC) and DC power supply modules
	Dual 10/100 Ethernet Ports—Flexible integration options for your high-performance network
	SNMP/HTTP management—Embedded HTTP server provides complete configuration and control using your web browser
	Quad T1/E1 ports for 120 RAS or uplink services—Terminate any combination of 120 modems/ISDN connections, or expand into remote locations and use the 3120 as a complete PoP solution

Applications
Model

Features

High-Density 96/120 Port RAS—Lowest-cost dial-up WAN access system available
Dynamic Modem/Digital Support—All modems support V.110, V.92, V.44, V.90, K56Flex, V.34+ or digital ISDN connections
Dual-Redundant Power Supplies—Supports two AC (115VAC or 230VAC), two DC, or a mix of AC (115VAC or 230VAC) and DC power supply modules
Standard Dual 10/100 Ethernet Ports—Flexible integration options for your high performance network
Web-Based—An embedded HTTP server provides complete configuration and control using standard web browsers
Made in the USA — This Patton equipment is designed by Patton engineers and built in our Gaithersburg, Maryland facility. Patton's American-made manufacturing process delivers high-quality networking solutions with reliability you can trust.

Ordering

Model #

Description

Availability

3120/120B/R-115

REMOTE/LAN ACCESS, 120 call, Redundant 115VAC PS

Special Order

Accessories

3120/120B/R-230

REMOTE/LAN ACCESS, 120 call, Redundant 230VAC PS

Special Order

Accessories

3120/60B/R-115

REMOTE/LAN ACCESS, 60 call, Redundant 115VAC PS

Special Order

Accessories

3120/60B/R-230

REMOTE/LAN ACCESS, 60 call, Redundant 230VAC PS

Special Order

Accessories

Dial-Up Remote Access Servers
ForeFront 3120 Dial-Up Remote Access Server (RAS), 16 to 120-port, V.92, V.110, V.90, K56Flex, V.34+, and ISDN

Lifecycle Change Notice (PDF) | This product is in sunset and not recommended for new installations.
